MSI GeForce RTX 5070 Ti 16G SHADOW 3X OC
Quick Product Overview
The MSI GeForce RTX 5070 Ti 16G SHADOW 3X OC is a factory-overclocked implementation of NVIDIA's Blackwell-based GeForce RTX 5070 Ti graphics processor.
MSI combines 8960 CUDA cores with 16GB of 28 Gbps GDDR7 operating across a 256-bit memory interface. MSI specifies a standard boost clock of 2482 MHz and an Extreme Performance setting of 2497 MHz through MSI Center.
The SHADOW 3X design uses three TORX FAN 5.0 fans, a large heatsink, nickel-plated copper baseplate, Core Pipes and a reinforcing backplate. The card measures 303 mm long and consumes 300W under MSI's published specification.
Key Specifications
| Model | G507T-16S3C |
|---|---|
| Graphics Processor | NVIDIA GeForce RTX 5070 Ti |
| Architecture | NVIDIA Blackwell |
| CUDA Cores | 8960 |
| Boost Clock | 2482 MHz |
| Extreme Performance | 2497 MHz through MSI Center |
| Video Memory | 16GB GDDR7 |
| Memory Speed | 28 Gbps |
| Memory Interface | 256-bit |
| Interface | PCI Express Gen 5 |
| DisplayPort | 3 × DisplayPort 2.1b |
| HDMI | 1 × HDMI 2.1b |
| Maximum Displays | 4 |
| Digital Maximum Resolution | 7680 × 4320 |
| HDCP | Supported |
| DirectX | DirectX 12 Ultimate |
| OpenGL | OpenGL 4.6 |
| Power Consumption | 300W |
| Recommended PSU | 750W |
| Power Connector | 1 × 16-pin |
| Card Dimensions | 303 × 121 × 49 mm |
| Card Weight | 994 g |
Performance & Use-Case Information
1440p Gaming
The RTX 5070 Ti performance class provides substantial GPU resources for high-quality and high-refresh-rate 1440p gaming.
4K Gaming
The combination of 8960 CUDA cores and 16GB GDDR7 also makes this card relevant to 4K gaming, depending on the title, graphics settings and enabled RTX features.
16GB GDDR7
Sixteen gigabytes of graphics memory provides substantial capacity for high-resolution textures and compatible GPU-accelerated workloads.
Blackwell Architecture
NVIDIA Blackwell provides current RTX 50-series graphics, ray-tracing and AI-acceleration technologies.
DLSS Technologies
Compatible games can use current NVIDIA DLSS technologies for AI-assisted image reconstruction, ray reconstruction and supported frame-generation features.
Creator Applications
NVIDIA CUDA, Tensor and RTX hardware can accelerate compatible rendering, video, AI and GPU-compute applications.
Cooling & Card Design
Triple-Fan Cooling
MSI uses three fans and a large heatsink to provide airflow across the SHADOW 3X thermal assembly.
TORX FAN 5.0
MSI's TORX FAN 5.0 design links fan blades with ring arcs and uses a fan cowl intended to stabilize and maintain high-pressure airflow.
Nickel-Plated Copper Baseplate
Heat from the GPU and graphics memory is captured by a nickel-plated copper baseplate before being transferred into the cooling assembly.
Core Pipes
MSI uses square-profile Core Pipes designed to maximize contact with the GPU baseplate and transfer heat through the heatsink.
Reinforcing Backplate
A structural backplate reinforces the length of the graphics card while completing the restrained SHADOW visual design.
Zero Frozr
MSI's Zero Frozr feature can stop the cooling fans during suitable low-load operating conditions to reduce unnecessary noise.
Platform & Compatibility
PCI Express Gen 5
MSI specifies PCI Express Gen 5 as the graphics-card interface. Builders should verify motherboard and chassis compatibility.
750W Recommended PSU
MSI recommends a 750W system power supply for the RTX 5070 Ti SHADOW 3X OC.
16-Pin GPU Power
The card uses one 16-pin supplementary power connector. MSI recommends an ATX 3.1 power supply.
303 mm Card Length
Builders should verify chassis clearance for the 303 × 121 × 49 mm graphics card.
Four Display Outputs
Three DisplayPort 2.1b connections and one HDMI 2.1b connection support as many as four displays.
MSI Software
MSI Center provides supported graphics-card configuration functions, while MSI Afterburner provides compatible monitoring and tuning controls.
Works Best With
High-Performance Modern CPU
A capable current processor helps avoid unnecessary CPU-side limitations when targeting high frame rates with this GPU class.
Quality 750W+ ATX 3.1 PSU
MSI recommends a 750W PSU and identifies an ATX 3.1 power supply as the recommended configuration for the card's single 16-pin connector.
1440p / 4K Display
The RTX 5070 Ti performance class is relevant to high-refresh-rate 1440p and high-resolution 4K gaming displays.
Memory, Power & Display Connectivity
16GB GDDR7
Sixteen gigabytes of dedicated graphics memory provides substantial capacity for modern games and compatible GPU-accelerated applications.
28 Gbps Memory
MSI specifies 28 Gbps GDDR7 operating across a 256-bit memory interface.
PCI Express Gen 5
The current-generation PCI Express interface connects the graphics processor to the host platform.
1 × 16-Pin Power
A single 16-pin connector supplies supplementary graphics-card power. MSI recommends an ATX 3.1 PSU.
3 × DisplayPort 2.1b
Three current-generation DisplayPort outputs provide flexible high-resolution monitor connectivity.
1 × HDMI 2.1b
HDMI 2.1b supports compatible high-resolution displays, including supported DSC, VRR and HDR configurations.
What Published Technical Information Shows
Factory-Overclocked Model
MSI specifies a 2482 MHz boost clock and a 2497 MHz Extreme Performance setting available through MSI Center.
8960 CUDA Cores
MSI documents 8960 CUDA cores for the GeForce RTX 5070 Ti graphics processor used by this SHADOW 3X OC model.
16GB / 256-Bit Memory
The card combines 16GB of 28 Gbps GDDR7 with a 256-bit graphics-memory interface.
Triple-Fan Thermal Design
MSI combines three TORX FAN 5.0 fans with a large heatsink, copper baseplate and Core Pipes.
300W Power Consumption
MSI publishes 300W graphics-card power consumption and recommends a 750W system power supply.
Current Display Standards
DisplayPort 2.1b and HDMI 2.1b provide current-generation connectivity for compatible gaming monitors and televisions.
Where Research Agrees & Differs
Documented Hardware
MSI documentation establishes the core specifications: RTX 5070 Ti, 8960 CUDA cores, 16GB GDDR7, 256-bit memory, PCIe Gen 5, 300W power consumption and four display outputs.
Real-World Results Vary
Published gaming and application results can differ according to processor, driver version, game or application version, resolution, graphics settings, cooling and test methodology.
Strengths & Limitations
Strengths
- NVIDIA Blackwell architecture
- 8960 CUDA cores
- 16GB GDDR7 graphics memory
- 28 Gbps memory speed
- 256-bit memory interface
- Factory-overclocked MSI configuration
- 2497 MHz Extreme Performance setting
- PCI Express Gen 5
- Triple TORX FAN 5.0 cooling
- 3 × DisplayPort 2.1b
- 1 × HDMI 2.1b
- Maximum four-display support
Limitations & Planning Considerations
- 300W published graphics-card power consumption
- 750W recommended system power supply
- Requires one 16-pin GPU power connector
- 303 mm length requires adequate chassis clearance
- 49 mm card thickness can affect adjacent expansion space
- Actual boost frequency varies with operating conditions
- Performance varies by game and graphics settings
- Retail pricing and availability can change quickly
Upgrade Considerations
Check Case Clearance
Verify support for the card's 303 × 121 × 49 mm dimensions, including clearance around front-mounted cooling hardware.
Check PSU Capacity
MSI recommends a 750W power supply. Builders should also account for the rest of the system's power requirements.
Plan the 16-Pin Connection
The card uses one 16-pin power connector and MSI recommends an ATX 3.1 PSU. Cable clearance should be considered during installation.
Alternatives to Consider
Other RTX 5070 Ti Models
Other RTX 5070 Ti implementations can be compared for cooler size, clock settings, acoustics, dimensions and current pricing.
Radeon RX 9070 XT
AMD's RDNA 4 RX 9070 XT is a useful alternative to compare for raster performance, ray tracing, software features, power requirements and current pricing.
GeForce RTX 5070
The non-Ti RTX 5070 occupies a lower performance tier and can be considered where system requirements or purchase cost are priorities.
Who Is It Best For?
High-Refresh 1440p Gamers
Users building powerful systems around high-refresh-rate 1440p gaming displays.
4K Gaming Systems
Buyers researching a GPU with substantial resources for high-resolution gaming and current RTX technologies.
Gaming & Creator Builds
Systems that can benefit from 16GB GDDR7 alongside NVIDIA CUDA, RTX and AI-acceleration technologies.
Rockin Box Tech Research Summary
The MSI GeForce RTX 5070 Ti 16G SHADOW 3X OC combines NVIDIA's Blackwell RTX 5070 Ti GPU with 16GB of high-speed GDDR7 and MSI's triple-fan SHADOW cooling design.
MSI specifies 8960 CUDA cores, 28 Gbps GDDR7, a 256-bit memory interface, a 2482 MHz boost clock and a 2497 MHz Extreme Performance setting through MSI Center.
The card measures 303 × 121 × 49 mm, consumes 300W and uses one 16-pin power connector. MSI recommends a 750W power supply and identifies an ATX 3.1 PSU as the recommended power configuration.
For buyers researching a high-performance RTX 5070 Ti, the SHADOW 3X OC combines 16GB of graphics memory, current Blackwell features, triple-fan cooling and modern display connectivity in MSI's comparatively understated SHADOW design.
Research Sources
MSI
GeForce RTX 5070 Ti 16G SHADOW 3X OC official specifications, clock speeds, memory, dimensions, cooling features, display outputs and power requirements.
NVIDIA
GeForce RTX 50-series Blackwell architecture, RTX platform, graphics technologies and current driver information.
Research Disclosure
Products are not necessarily physically tested by Rockin Box Tech.
Graphics performance, clock speeds, temperatures, acoustics, power consumption and application performance can vary according to processor, motherboard, memory, BIOS, graphics driver, operating system, case airflow, cooling, power configuration, application or game version, graphics settings, resolution and operating conditions.
Product specifications, firmware and driver support, pricing and availability may change after this review is published.
