Kingston FURY Renegade RGB DDR5-6400 CL32
32GB high-performance DDR5 kit with two 16GB modules, 6400 MT/s speed, CL32 latency, Intel XMP 3.0 and customizable RGB lighting.
Quick Product Overview
The Kingston FURY Renegade RGB DDR5-6400 CL32 kit reviewed here is part number KF564C32RSAK2-32. It contains two 16GB DDR5 modules for a total capacity of 32GB.
Kingston rates the primary performance profile at 6400 MT/s with 32-39-39 timings at 1.40V.
This is an Intel XMP 3.0 memory kit aimed at enthusiast and gaming systems where higher memory frequency, low latency and RGB styling are all desired.
Key Specifications
| Manufacturer | Kingston |
|---|---|
| Product Family | Kingston FURY Renegade RGB |
| Part Number | KF564C32RSAK2-32 |
| Total Capacity | 32GB |
| Module Configuration | 2 × 16GB |
| Memory Type | DDR5 |
| Memory Format | 288-pin UDIMM |
| Rated Speed | DDR5-6400 / 6400 MT/s |
| Primary XMP Timings | 32-39-39 |
| CAS Latency | CL32 |
| Rated Voltage | 1.40V |
| Performance Profile | Intel XMP 3.0 |
| Default JEDEC Speed | DDR5-4800 |
| Default JEDEC Timings | CL40-39-39 |
| Default Voltage | 1.10V |
| Module Organization | 1Rx8 |
| Error Correction | On-die ECC |
| Buffered / Registered | Non-ECC unbuffered DIMM |
| Module Height | 44.0 mm with RGB heat spreader |
| Lighting | Customizable RGB |
| RGB Synchronization | Kingston FURY Infrared Sync Technology |
XMP Profiles
Profile #1
DDR5-6400 with CL32-39-39 timings at 1.40V. This is the kit's primary advertised performance profile.
Profile #2
DDR5-6000 with CL32-38-38 timings at 1.35V. This provides a useful fallback when DDR5-6400 is not stable on a particular CPU or motherboard combination.
Profile #3
DDR5-4800 with CL38-38-38 timings at 1.10V, providing an additional lower-frequency profile.
Performance & Use-Case Information
Gaming
DDR5-6400 provides high bandwidth for modern gaming systems, particularly when paired with a processor and motherboard capable of maintaining the rated memory speed.
Productivity
The combination of 32GB capacity and high DDR5 bandwidth is suitable for content creation, multitasking and many professional desktop workloads.
32GB Capacity
Two 16GB modules provide a practical capacity for modern gaming and general-purpose systems without filling all four motherboard DIMM slots.
CL32 Latency
CL32 is a relatively aggressive latency specification at DDR5-6400 and positions the kit toward performance-focused systems.
Multiple XMP Profiles
Kingston includes three XMP profiles, making it easier to choose between maximum rated speed and more conservative settings.
RGB Builds
The integrated light bar and Kingston FURY synchronization technology make this version especially suited to showcase PCs.
Speed, Latency & Voltage
Kingston's primary XMP profile operates at DDR5-6400 CL32-39-39 at 1.40V. The memory defaults to standard DDR5-4800 CL40-39-39 at 1.10V when the performance profile is not enabled.
The secondary DDR5-6000 profile is particularly useful because not every processor memory controller is equally comfortable operating at DDR5-6400.
This gives the Renegade kit more flexibility than memory kits that provide only one performance-oriented profile.
Platform & Compatibility
Intel XMP 3.0
This exact kit is designed around Intel XMP 3.0 profiles for compatible Intel DDR5 systems.
Motherboard Support
Kingston validates FURY memory with major motherboard manufacturers, but exact supported speeds vary by board and BIOS.
Motherboard QVL
Checking the motherboard manufacturer's Qualified Vendor List remains advisable before purchasing a high-speed DDR5 kit.
CPU Memory Controller
DDR5-6400 operation also depends on the quality and capability of the processor's integrated memory controller.
Works Best With
These examples describe the type of system that suits this memory. Always verify motherboard QVL support and BIOS compatibility.
Modern Intel DDR5 CPU
The kit is most naturally paired with a modern Intel desktop processor and motherboard capable of using XMP 3.0.
High-Speed DDR5 Motherboard
A motherboard with strong DDR5 memory support is important when targeting the full 6400 MT/s XMP profile.
Kingston FURY CTRL
Kingston's FURY CTRL software provides customization for compatible RGB lighting effects.
RGB Lighting & Physical Design
The Renegade RGB uses a black-and-silver aluminum heat spreader topped by a customizable RGB light bar.
Kingston's FURY Infrared Sync Technology is designed to keep the lighting effects synchronized between installed modules.
Kingston lists the RGB model at approximately 44 mm tall. This is still manageable in many builds, but users with large air coolers should check DIMM clearance.
What Independent Reviewers Found
Tom's Hardware — DDR5-6400 Positioning
Tom's Hardware found the Renegade DDR5-6400 C32 family to provide respectable performance and described DDR5-6000 through DDR5-6400 as a useful speed range for many consumers and professionals.
Multiple Profiles
Independent testing highlighted Kingston's inclusion of multiple XMP profiles as a practical advantage when a system cannot reliably operate the highest profile.
Manual Tuning
Testing of another Renegade DDR5-6400 C32 capacity showed that tighter timings were possible with additional voltage, though manual tuning results should never be assumed to apply equally to every kit.
Where the Research Is Consistent
Strong Points
- DDR5-6400 rated speed
- CL32 latency
- 32GB dual-channel capacity
- Three Intel XMP 3.0 profiles
- 1Rx8 module organization
- Customizable RGB lighting
- Infrared Sync lighting technology
- Aluminum heat spreaders
Important Context
- DDR5-6400 is an overclocked profile
- 1.40V required for primary XMP profile
- High-speed memory stability varies by CPU
- Motherboard and BIOS support matter
- 44 mm module height can affect cooler clearance
- Independent review data is partly family-level
Strengths & Limitations
Strengths
- 32GB total capacity
- 2 × 16GB configuration
- DDR5-6400
- CL32
- 32-39-39 XMP timing specification
- Three XMP 3.0 profiles
- Fallback DDR5-6000 profile
- Customizable RGB
- On-die ECC
- Premium aluminum heat spreader
Limitations
- Requires XMP for advertised performance
- DDR5-6400 may not be stable on every CPU
- Higher 1.40V operating voltage at full speed
- Requires DDR5-compatible motherboard
- RGB version is taller than non-RGB model
- Manual overclocking results are not guaranteed
Upgrade Considerations
From 16GB
Moving to 32GB gives modern games, browsers, creative software and background applications more memory headroom.
From Slower DDR5
DDR5-6400 can improve memory bandwidth over lower-frequency DDR5, though real-world performance improvements vary by application and processor.
For New Intel Builds
The three XMP profiles make this kit flexible for systems that may not reach the full DDR5-6400 configuration reliably.
Alternatives to Consider
G.SKILL Trident Z5 DDR5-6400
Another enthusiast-focused DDR5 family with high-speed Intel XMP configurations and premium styling.
Corsair Vengeance RGB DDR5-6000 CL30
A slightly lower-frequency option with tight CL30 timings and Corsair's iCUE lighting ecosystem.
TEAMGROUP T-FORCE DELTA RGB
A competing RGB gaming-memory family available across a broad range of DDR5 speeds and timings.
Who Is It Best For?
Intel Gaming Systems
Builders looking for a high-speed 32GB DDR5 kit with an Intel XMP 3.0 profile.
Enthusiast Builds
Users who want DDR5-6400 performance while retaining fallback profiles for easier system tuning.
RGB Showcase PCs
Systems where synchronized lighting and premium memory styling are important parts of the finished build.
Rockin Box Tech Research Summary
Kingston's documentation shows the FURY Renegade RGB DDR5-6400 CL32 32GB kit to be a high-performance Intel-focused DDR5 package with strong speed, competitive latency and unusually flexible XMP configuration.
The exact KF564C32RSAK2-32 kit provides two 16GB single-rank modules, DDR5-6400 operation, CL32-39-39 timings and 1.40V operation through its primary Intel XMP 3.0 profile.
Kingston also includes DDR5-6000 and DDR5-4800 XMP profiles, giving users additional options if the processor or motherboard cannot reliably operate the full DDR5-6400 profile.
RGB lighting, Infrared Sync Technology and the aluminum heat spreader make this particularly suitable for performance-focused gaming and showcase systems.
